Performance parameters
Light Source:
Visible Laser diode ,650nm
Scan rate:
300scans per second
Scanning Angle:
±60°±65°±42°(left right, front back, turn)
Scanning width:
30mm@ scanning window 220mm@200mm
Scanning type:
Single-line
Resolution:
0.1mm(4mil)at pcs 0.9
Depth of scanning field:
0-250mm (0.33mm.PCS 90%)
Print Contrast Minimum:
30%,minimum reflective difference(@650nm)
Indicator light:
LED DIODE
Interface Support
USB,PS2,RS232
Minimum Resolution:
3mil
Physical Characteristic
Voltage:
DC 5V
Current:
85mA(Operating mode),36mA(Quiescent current)
Dimensions:
L100mm*W72mm*H176mm
Weight:
256g(include the cable)
USB:
2M(Can remove)
Housing Materials:
ABS+PC
User Environment:
Operating Temperature:
-10°~50°
Storage Temperature:
-40°~70°
Operating Humidity:
5~95% relative humidity, on-condensing
Environment luminance:
5,000 Lux Max(Fluorescence)
IP Level:
IP54
Drop Specification:
withstands multiple 3m drops to concrete
Safe:
EMI/RFI:
FCC class A and CE
Laser safety:
CDRH class 2 laser product
Decode Capability:
UPC-A,UPC-E,EAN-13,EAN-8,ISBN/ISSN,Code 39,
code39 full ASCII, Interleaved 2 of 5, Industrial 2 of 5,
Matrix 2 of 5 ,codabar(NW7),code128,code 93 ,
code 93 full ASCII,code 11(USD-8),MSI/Plessey,UK/Plessey,UCC/EAN 128,
GS1 Data Bar, China Post code, etc.
Certificate
RoHS
